We Can Handle It.

Flexible handling equipment for stores and factories

Our KBK stacker cranes make it possible to complete all storage and handling tasks in one operating cycle without the need for ladders, order-picking trolleys or similar equipment. Unit loads, containers or pallets weighing up to 500 kg can be safely and reliably transported, sorted and stored.

Combination of KBK double-girder suspension crane and special stacker trolley
Load handling attachments to match the load – forks, prongs, grippers and other attachments can be supplied

Further information

The benefits at a glance

Technical data

A KBK stacker crane mainly consists of a KBK double-girder suspension crane combined with a special stacker trolley and a load handling attachment.

Stacker trolley selection table					Stacker trolley crane data
Lifted load	b	Size	H	T	KBK	l_HT	l_Kr	l_W KBK II-L	l_W KBK II
[kg]	[mm]		[mm]	[mm]		[mm]	[mm]	[mm]	[mm]
80	900	2	4,110	3,420	II-L	5,000	4,500	4,000	6,000
					II	6,000	5,500	3,500	6,000
	1200	3	5,110	4,420	II-L	5,000	4,500	3,000	5,000
					II	6,000	5,500	3,000	5,000
100	800	2	4,110	3,420	II-L	5,000	4,500	3,500	6,000
					II	6,000	5,500	3,500	5,500
	1000	3	5,110	4,420	II-L	5,000	4,500	3,000	5,000
					II	6,000	5,500	3,000	4,500
125	700	2	4,110	3,420	II-L	5,000	4,500	3,500	5,500
					II	6,000	5,500	3,500	5,500
	900	3	5,110	4,420	II-L	5,000	4,500	3,000	4,500
					II	6,000	5,500	3,000	4,500
160	550	2	4,110	3,420	II-L	5,000	4,500	3,000	5,000
					II	6,000	5,500	3,000	5,000
	800	3	5,110	4,420	II-L	5,000	4,500	2,500	4,000
					II	6,000	5,500	2,500	4,000
200	480	2	4,110	3,420	II-L	5,000	4,500	2,500	4,500
					II	6,000	5,500	2,500	4,500
	650	3	5,110	4,420	II-L	5,000	4,500	2,000	4,000
					II	6,000	5,500	2,000	4,000
250	400	2	4,110	3,420	II-L	5,000	4,500	2,500	4,500
					II	6,000	5,500	2,500	4,000
	600	3	5,110	4,420	II-L	5,000	4,500	2,000	4,000
					II	6,000	5,500	2,000	3,500
315	370	2	4,110	3,420	II-L	4,500	4,000	2,000	4,000
					II	5,000	4,500	2,000	3,500
	600	3	5,110	4,150	II-L	4,500	4,000	1,500	4,000
					II	5,500	5,000	1,500	3,500
400	350	2	4,110	3,420	II-L	4,500	4,000	1,500¹⁾	4,000¹⁾
					II	5,000	4,500	1,500¹⁾	3,500¹⁾
	600	3	5,110	4,150	II-L	4,000	3,500	1,500¹⁾	3,500¹⁾
					II	5,000	4,500	1,500¹⁾	3,000¹⁾
500	300	2	4,110	3,420	II-L	3,500	3,000	-	3,500¹⁾
					II	4,500	4,000		3,500¹⁾
	600	3	5,110	4,150	II	4,500	4,000		3,000¹⁾

¹⁾ 2 x double trolley at each end of the crane for I_HT > I_KR + 240 mm. Dimension h₃ increases by + 15mm.

b = Load centre distance
H = Unit height
T = Fork lifting height
I_HT = Crane girder length
L_Kr = Crane span dimension
l_w = Distance between supports

Size	Crab span dimension l_Ka and e_Ka1 [mm]	Dimensions [mm]					Max. lifting speed [mm]	Weight for max. H [kg]
		X_max	c	d	f ²⁾	f ²⁾		300
2	800	1,000	650	160	135	135	8.0	400
3	1,000	1,000	650	80	80	85
3	1,000	1,000	920	80	80	85

²⁾ Dimension f for pivot centre
